E02016 2/02 Electrical Propulsion Components E2-17
TABLE I. 2-DIGIT DISPLAY PANEL CODES (Cont.)
EVENT
CODE
EVENT
DESCRIPTION
EVENT RESTRICTION
DETECTION
INFORMATION
EVENT VALUES
Decay
Time
Lock
Limit
Accept
Limit
Window
Limit
83
Alternator Field
Current Level
Recorded in memory only.
Alternator field current slow
to decay.
Check for: Defective shunt,
iso-amp, or FB102/140 card.
N/A N/A 10 1
88
Lamp Test None
Lamp test in progress.
• Not a true event.
• Not logged.
90
Battery Volts Low
System Event
• In ACCEL: No propel and
turn on SYSFLT light.
• In RETARD: Turn on SYS-
FLT light only.
Battery volts low. Less than
21 volts for 4 seconds and
engine speed greater than
600 rpm.
Check for: Check 24V alter-
nator or batteries.
3600 3 10 2
91
Battery Volts High Recorded in memory only.
Battery volts high. Greater
than 32 volts for 4 seconds.
Check 24V alternator regula-
tor.
N/A N/A 10 1
92
Bad Engine
Sensor
Recorded in memory only.
Engine sensor output outside
normal range.
Check sensor and wiring.
N/A N/A 10 3
98
Data Store Recorded in memory.
Indicates a data snapshot
has been initiated by manual
means.
N/A N/A 11 10
99
Software Recorded in memory.
Software problem. The allo-
cated fault registers in mem-
ory are full, insufficient space
exists.
Reset event list, erase
events.
1800 3 5 1
