E2-50 Electrical Propulsion Components 2/02 E02016
TABLE III. STATISTICAL DATA CODES - COUNTERS (Cont.)
PAR
No.
DESCRIPTION UNITS COUNT CONDITIONS
29 Propel Mode Occurrences
Number of times Propel Contactor sequence has been completed or Propel
mode entered
30 Coast Mode Occurrences Number of times Coast mode entered
31 P1 Pickup Occurrences Number of times P1 feedback has changed from false to true
32 P2 Pickup Occurrences Number of times P2 feedback has changed from false to true
33 RP1 Pickup Occurrences Number of times RP1 feedback has changed from false to true
34 RP2 Pickup Occurrences Number of times RP2 feedback has changed from false to true
35 RP3 Pickup Occurrences Number of times RP3 feedback has changed from false to true
36 RP4 Pickup Occurrences Number of times RP4 feedback has changed from false to true
37 RP5 Pickup Occurrences Number of times RP5 feedback has changed from false to true
38 RP6 Pickup Occurrences Number of times RP6 feedback has changed from false to true
39 RP7 Pickup Occurrences Number of times RP7 feedback has changed from false to true
40 RP8 Pickup Occurrences Number of times RP8 feedback has changed from false to true
41 RP9 Pickup Occurrences Number of times RP9 feedback has changed from false to true
42 GF Pickup Occurrences Number of times GF feedback has changed from false to true
43 GFR Pickup Occurrences Number of times GFR feedback has changed from false to true
44 MF Pickup Occurrences Number of times MF feedback has changed from false to true
48 DBUP & >8 MPH Occurrences Number of times dump body is raised with truck speed above 8 MPH
49 Srv Brk >8 MPH Occurrences Number of times service brake has been applied with truck speed above 8 MPH
50 Park Brake Occurrences Number of times Park Brake Off has changed from false to true
51 Service Brake Occurrences Number of times Service Brake Pressure Switch has changed from false to true
52 Loaded Switch Occurrences
Number of times Two-Speed Overspeed has changed from false to true
. . . (empty to loaded)
53 Reverser Moves Occurrences
Number of times Reverser feedback has changed from FORWARD to REVERSE
or REVERSE to FORWARD
54 SS Move > 2 MPH Occurrences
Number of times Selector Switch was moved with truck speed greater than “no
motion” (2 MPH)
55 CPR Pickup Occurrences Number of times CPR feedback has changed from false to true
56 Engine Starts Occurrences Number of times engine speed goes from <450 RPM to >450 RPM
57 2dd Reset Switch Occurrences Number of times reset button on 2 Digit Display has been pushed
58 Both AS & RS Occurrences Number of times AS & RS activated at same time
59 AS & Service Brake Occurrences Number of times AS and service brake activated at same time
60 RS & Service Brake Occurrences Number of times RS and service brake activated at same time
61 AS & Temp >220°C Occurrences
Number of times AS is activated with either motor temperature greater than
220°C
62 RS & nomotion Occurrences Number of times RS is activated at truck speeds below “no motion” (2 MPH)
63 RSC Switch On Occurrences Number of times Retard Speed Control switch is turned On
64 RSC Pot Moved Occurrences
Number of times Retard Speed Control pot is moved more than 1 MPH while
RSC is On.
65 Test Digital Output Occurrences
Number of times “MANUAL DIGITAL OUTPUT TEST” screen has been selected
at the “SPECIAL OPERATION WITH ENGINE STOPPED TEST” menu
66 Program Truck Occurrences Number of times PTU has been used to program the truck
To Next Page
