TABLE IV. STATISTICAL DATA CODES - PROFILES (Cont.)
PAR
No.
DESCRIPTION COUNT CONDITIONS BUCKET No.
TEMP RANGE
(°C)
88
M1 Temp °C
(in seconds)
This is a histogram of Motor #1 temperature.
. . . . Sample time is 60.0 seconds
. . . . The clock will start whenever control power (CPR) is on.
The histogram breaks the temperature spectrum into 17 buckets
defined at right, and displays the time spent in each bucket.
1 -40 to 100
2 101 to 110
3 111 to 120
4 121 to 130
5 131 to 140
6 141 to 150
7 151 to 160
8 161 to 170
89
M2 Temp °C
(in seconds)
This is a histogram of Motor #2 temperature.
. . . . Sample time is 60.0 seconds
. . . . The clock will start whenever control power (CPR) is on.
The histogram breaks the temperature spectrum into 17 buckets
defined at right, and displays the time spent in each bucket.
9 171 to 180
10 181 to 190
11 191 to 200
12 201 to 210
13 211 to 220
14 221 to 230
15 231 to 240
16 241 to 250
17 251 to 9999
PAR
No.
DESCRIPTION COUNT CONDITIONS
BUCKET
No.
TRUCK
SPEED
MPH
ENGINE SPD
RPM
90
Truck Speed
MPH
(in seconds)
This is a histogram of truck speed for all modes of operation.
. . . . Sample time is 1.0 second
. . . . The clock will start whenever control power (CPR) is
on.
The buckets are defined in the Truck Speed column at right:
1 0 to 1 600 & below
2 2 to 3 601 to 800
3 4 to 6 801 to 900
4 7 to 9 901 to 1000
5 10 to 12 1001 to 1100
6 13 to 15 1101 tto 1200
7 16 to 18 1201 to 1300
8 19 to 21 1301 to 1400
91
Engine Speed
RPM
(in seconds)
This is a histogram of engine speed in RPM for all modes of
operation.
. . . . Sample time is 1.0 second
. . . . The clock will start whenever control power (CPR) is
on.
The buckets are defined in the Engine Speed column at
right:
9 22 to 24 1401 to 1500
10 25 to 27 1501 to 1600
11 28 to 30 1601 to 1700
12 31 to 33 1701 to 1800
13 34 to 36 1801 to 1900
14 37 to 39 1901 to 2000
15 40 to 42 2001 to 2100
16 43 to 45 2101 to 2200
17 45 & above 2200 & above
