N05056 Operator Controls N5-21
A5, D5, E5, A6, B6, C6, D6,
E6: Blank
(Reserved for future use)
(7) Hazard Warning Lights
The hazard warning light
switch flashes all the turn sig-
nal lights. Pressing the bottom
side of the rocker switch
(toward the triangle) activates
these lights. Pressing the top
side of the rocker switch
(toward the “OFF” symbol)
turns these lights off.
(8) Lamp Test Switch
The Lamp Test switch is pro-
vided to allow the operator to
test the indicator lamps prior to
starting the engine. Any lamp
bulbs which do not illuminate
should be replaced before
operating the truck.
Lamp Test:
To test the lamps and the warning horn:
1. Turn the key switch to the RUN position.
2. Press the bottom of the rocker switch for the
"check" position:
3. All lamps should illuminate unless they relate to
optional equipment not installed on the truck.
4. The warning horn should sound.
5. Releasing the spring-loaded switch will allow the
switch to return to the “Off” position.
If any lamp does not illuminate, the bulb should be
replaced before operating the truck.
