MAINTENANCE
MAINTENANCE PROCEDURE
MAINTENANCE
MAINTENANCE PROCEDURE
5. If small holes or thinner parts are found on the element when
it is checked by shining a light through it after cleaning, replace
the element.
NOTICE
When cleaning the element, do not hit it or beat it against something.
Do not use an element whose folds or gasket or seal are damaged.
Wrap unused element and store them in a dry place.
CAUTION
When installing the cover (3), check O-ring (7) and replace it if there are any scratches or damage.
6. Set the cleaned outer element in position, then secure cover (3) with mounting clips (2).
7.
Press the button of dust indicator (1) to return the red piston to
its original position.
Replacing Element
1.
Open the battery room door on the left side of the machine,
remove clips (2) at 3 places, then take out cover (3).
4 - 19
To Next Page
