Kontron CP3002 - Operational Limits for the CP3002; CP3002 with I7-660 UE, 1.33 Ghz; CP3002 with I7-620 LE, 2.0 Ghz

CP3002 Thermal Considerations
ID 1042-9252, Rev. 2.0 Page 6 - 7
P R E L I M I N A R Y
6.4.1 Operational Limits for the CP3002
Figure 6-1: CP3002 with i7-660UE, 1.33 GHz
Figure 6-2: CP3002 with i7-620LE, 2.0 GHz
Volumetric Flow Rate (CFM)
Volumetric Flow Rate (m /h)
3
Airflow (m/s)
Maximum Processor Workload and
Graphics Controller in Idle State
recommended
operating range
Maximum Processor and Graphics
Controller Workload
Volumetric Flow Rate (CFM)
Volumetric Flow Rate (m /h)
3
Airflow (m/s)
Maximum Processor Workload and
Graphics Controller in Idle State
recommended
operating range
Maximum Processor and Graphics
Controller Workload
