Installation CP3002
Page 3 - 10 ID 1042-9252, Rev. 2.0
P R E L I M I N A R Y
The following chapters provide information regarding installation aspects of peripheral devices.
3.5.1 USB Device Installation
The CP3002 supports all USB Plug and Play computer peripherals (e.g. keyboard, mouse,
printer, etc.).
3.5.2 Installation of External Serial ATA Devices
The following information pertains to external SATA devices which may be connected to the
CP3002 via normal cabling.
Some symptoms of incorrectly installed SATA devices are:
• Device on a SATA channel does not spin up: check power cables and cabling. May also
result from a bad power supply or SATA device.
The SATA connector on the CP3002 provides only a data connection. The power for this
device must be supplied by a separate connector. For further information, refer to the
respective documentation of the device.
• SATA device fail message at boot-up: may be a bad cable or lack of power going to the
drive.
3.5.3 SATA Flash Module Installation
A SATA Flash module may be connected to the 4HP CP3002 via the onboard connector J5.
This optionally available module must be physically installed on the CP3002 prior to installation
of the CP3002 in a system.
During installation it is necessary to ensure that the SATA Flash module is properly seated in
the onboard connector J5, i.e. the pins are aligned correctly and not bent, prior to fixing the
SATA Flash module with the respective screw
The SATA Flash module cannot be used in conjunction with the CP3002-HDD module.
3.5.4 2.5” HDD/SSD Installation
One 2.5” SATA HDD/SSD may be connected to the 8HP CP3002 via the CP3002-HDD and the
respective SATA connector. For further information regarding the CP3002-HDD module, refer
to Appendix A in this manual.
Note ...
All USB devices may be connected or removed while the host or other
peripherals are powered up.
Note ...
Only qualified SATA Flash modules from Kontron are authorized for use with
the CP3002. Failure to comply with the above will void the warranty and may
result in damage to the board or the system.
