Kontron CP3002 - Technical Specification

CP3002 Introduction
ID 1042-9252, Rev. 2.0 Page 1 - 9
P R E L I M I N A R Y
1.5 Technical Specification
Table 1-1: CP3002 Main Specifications
FEATURES SPECIFICATIONS
Processor and Memory
CPU
The CP3002 supports the following microprocessors:
• Intel® Core™ i7-610E (SV), 2.53 GHz, 4 MB L3 cache
• Intel® Core™ i7-620LE (LV), 2.0 GHz, 4 MB L3 cache
• Intel® Core™ i7-660UE (ULV), 1.33 GHz, 4 MB L3 cache
• Intel® Celeron® U3405 (ULV), 1.07 GHz, 2 MB L3 cache
Further processor features:
• Two execution cores
• Intel® Hyper-Threading Technology (Core™ i7)
• Intel® 64 Architecture
• Intel® Turbo Boost Technology (Core™ i7)
• Intel® Intelligent Power Sharing (Core™ i7)
• System Memory interface with optimized support for dual-channel
DDR3 SDRAM memory at 1066 MHz with ECC
• Integrated 2D and 3D Graphics Engines
• DMI and FDI interfaces to the Intel® QM57 chipset
• Two x8 PCI Express 2.0 ports operating at 2.5 GT/s
Please contact Kontron for further information concerning the suitability of
other Intel processors for use with the CP3002.
Memory
Main Memory:
• Up to 8 GB, dual-channel DDR3 SDRAM memory with ECC running at
1066 MHz on two SODIMM sockets
Cache Structure:
• 64 kB L1 cache for each core
• 32 kB instruction cache
• 32 kB data cache
• Up to 512 kB L2 shared instruction/data cache for each core
• Up to 4 MB L3 shared instruction/data cache shared between both cores
Flash Memory:
• Two redundant SPI boot flashes (2 x 8 MB) for two separate uEFI BIOS
images
• Up to 16 GB NAND flash via an onboard Serial ATA Flash module (SSD)
Serial EEPROM with 64 kbit
