Kontron CP3002 - SATA Flash Module Layout (Top View); SATA Flash Module Layout (Bottom View)

SATA Flash Module CP3002
Page C - 4 ID 1042-9252, Rev. 2.0
P R E L I M I N A R Y
C.2 SATA Flash Module Layout
The SATA Flash module includes one board-to-board connector, J1, for connection to the
CP3002.
Figure C-1: SATA Flash Module Layout (Top View)
Figure C-2: SATA Flash Module Layout (Bottom View)
NAND
Flash
NAND
Flash
SATA
NAND Flash
Controller
J1
