CP3002 Functional Description
ID 1042-9252, Rev. 2.0 Page 2 - 19
P R E L I M I N A R Y
2.11.10.2 CompactPCI Connectors J1 and J2 Pinouts
The CP3002 is provided with two 2 mm x 2 mm pitch female CompactPCI connectors, J1 and
J2.
The legacy IDE interrupts INTP (CompactPCI specification pin D4) and INTS (CompactPCI
specification pin E4) are not implemented on the CP3002. Therefore, pins D4 and E4 are re-
served.
The IPMB system management bus (CompactPCI specification pins A4, B17, C17) is not im-
plemented on the CP3002. Therefore, pin A4 is not connected and pins B17 and C17 are re-
served.
For further information regarding the above-mentioned reserved pins, please contact Kontron.
Table 2-12: CompactPCI Connector J1 System Controller Slot Pinout
PIN ROW Z ROW A ROW B ROW C ROW D ROW E ROW F
25 NC 5V REQ64# ENUM# 3.3V 5V GND
24 NC AD[1] 5V V(I/O) AD[0] ACK64# GND
23 NC 3.3V AD[4] AD[3] 5V AD[2] GND
22 NC AD[7] GND 3.3V AD[6] AD[5] GND
21 NC 3.3V AD[9] AD[8] M66EN C/BE[0]# GND
20 NC AD[12] GND V(I/O) AD[11] AD[10] GND
19 NC 3.3V AD[15] AD[14] GND AD[13] GND
18 NC SERR# GND 3.3V PAR C/BE[1]# GND
17 NC 3.3V RSV RSV GND PERR# GND
16 NC DEVSEL# PCIXCAP V(I/O) STOP# LOCK# GND
15 NC 3.3V FRAME# IRDY# BDSEL# TRDY# GND
12-14 Key Area
11 NC AD[18] AD[17] AD[16] GND C/BE[2]# GND
10 NC AD[21] GND 3.3V AD[20] AD[19] GND
9 NC C/BE[3]# NC AD[23] GND AD[22] GND
8 NC AD[26] GND V(I/O) AD[25] AD[24] GND
7 NC AD[30] AD[29] AD[28] GND AD[27] GND
6 NC REQ0# CPCI_PRESENT# 3.3V CLK0 AD[31] GND
5NCNC NC RST#GNDGNT0#GND
4 NC NC HEALTHY# V(I/O) RSV RSV GND
3 NC INTA# INTB# INTC# 5V INTD# GND
2NCTCK5V TMSNC TDI GND
1 NC 5V NC TRST# NC 5V GND
