CP3002 Functional Description
ID 1042-9252, Rev. 2.0 Page 2 - 17
P R E L I M I N A R Y
2.11.9.4 Board Insertion/Replacement under Power
The following features are implemented on the CP3002:
• Power ramping
• ENUM signal handling (hot swapping of peripheral boards)
Power ramping on the CP3002 provides the hot plug functionality on the power interface. The
PCI signal interface does not provide hot swap functionality. No microswitch, no blue LED and
no signal precharge are provided on the CP3002.
The ENUM signal on the CP3002 allows for hot swapping of peripheral boards with hot swap
capability when the CP3002 is installed in the system controller slot.
2.11.9.5 Power Ramping
On the CP3002 a special power controller is used to ramp up the onboard supply voltages. This
is done to avoid transients on the +3.3V and +5V power supplies from the system. When the
power supply is stable, the power controller generates an onboard reset to put the board into
a defined state.
2.11.9.6 ENUM# Interrupt
If the board is operated in the system controller slot, the ENUM signal is an input.
Note ...
The CP3002 itself is not hot swappable when inserted in a system controller slot.
When inserted in a peripheral slot, the CP3002 is hot pluggable.
