4.3.13 Board ID Low Byte Register (BIDL)
Each Kontron board is provided with a unique 16-bit board-type identifier in the form of a
hexadecimal number. The following register indicates the low byte value of the board ID.
Table 4-15: Board ID Low Byte Register (BIDL)
REGISTER NAME BOARD ID LOW BYTE REGISTER (BIDL)
ADDRESS 0x28D
BIT NAME DESCRIPTION
RESET
VALUE
ACCESS
7 - 0 BIDL Board identification:
CP3002: 0xB320
0x20 R
Note ...
The Board ID High Byte Register is located in the address 0x288.
