4.3.10 Board and PLD Revision Register (BREV)
The Board and PLD Revision Register signals to the software when differences in the board
and the Programmable Logic Device (PLD) require different handling by the software. It starts
with the value 0x00 and will be incremented with each change in hardware as development
continues.
4.3.11 Geographic Addressing Register (GEOAD)
This register holds the CompactPCI geographic address.
Table 4-12: Board and PLD Revision Register (BREV)
REGISTER NAME BOARD AND PLD REVISION REGISTER (BREV)
ADDRESS 0x289
BIT NAME DESCRIPTION
RESET
VALUE
ACCESS
7 - 4 BREV Board revision N/A R
3 - 0 PREV PLD revision N/A R
Table 4-13: Geographic Addressing Register (GEOAD)
REGISTER NAME GEOGRAPHIC ADDRESSING REGISTER (GEOAD)
ADDRESS 0x28A
BIT NAME DESCRIPTION
RESET
VALUE
ACCESS
7 - 5 Res. Reserved 000 R
4 - 0 GA Geographic address N/A R
