CP3002 SATA Flash Module
ID 1042-9252, Rev. 2.0 Page C - 3
P R E L I M I N A R Y
C. SATA Flash Module
The 4HP CP3002 provides an optional SATA Flash module with up to 16 GB NAND Flash
memory. The SATA Flash module is connected to the CP3002 via the board-to-board
connectors J5 located on the CP3002 and J1 located on the SATA Flash module. The SATA
Flash module has been optimized for embedded systems providing high performance,
reliability and security. The SATA Flash module cannot be used in conjunction with the
CP3002-HDD module.
C.1 Technical Specifications
Note ...
Write protection is available for this module. Contact Kontron for further assis-
tance if write protection is required.
Note ...
If the SATA Flash module is mounted on the CP3002, the CP3002-HDD mod-
ule cannot be used on the CP3002.
Either the SATA Flash module or the CP3002-HDD module can be mounted
on the CP3002.
Table C-1: SATA Flash Module Specifications
SATA FLASH MODULE SPECIFICATIONS
Interface
Board-to-Board Connector One 18-pin, female, board-to-board connector, J1
Memory
Memory Up to 16 GB SLC-based NAND Flash memory
• Built-in full hard disk emulation
• Up to 50 MB/s read rate
• Up to 45 MB/s write rate
General
Power Consumption typ. 0.5 W
3.3 V supply
Temperature Range Operational: 0°C to +60°C Standard
-40°C to +85°C Extended
Storage: -40°C to +85°C
Climatic Humidity 93% RH at 40°C, non-condensing (acc. to IEC 60068-2-78)
Dimensions 38 mm x 27 mm
Board Weight ca. 7 grams
