Effects
84
Level controls
Additional level-related parameters may be available on-screen, depending on the effect Type.
Input Trim
[-Inf, -84.9…0.0 dB]
This controls the volume level into the effect. Use this to alter the response of effects such as the Waveshaper, or to
compensate for gain increases in effects such as the Talking Modulator.
Volume
[-Inf, -84.9…+12.0 dB]
This control the post-Drive output of the Guitar Amp. Use it to compensate for level changes caused by Drive.
Output Level
[-Inf, -84.9…0.0 dB]
This controls the output volume from the effect. Use it to compensate for level changes in effects such as the
Waveshaper.
Gain Adjust
[-Inf, -84.9…+24.0 dB]
This is similar to Output Level, but provides up to 24dB of gain. It appears only for the Modern Compressor.
Edit page
The EDIT 1/2/3 controls (E1/E2/E3 on the display) are macros which may control multiple internal parameters, and
which may be set up differently for each Preset. There are general conventions for the EDIT knobs of each effect Type,
as reflected in the on-screen labels.
