Modulation Processors
73
Modulation Processors
Overview
Modulation Processors transform a modulation signal to make it into something new. e original modulation signal
also remains available. ere are two Modulation Processors per Program.
e Modulation Processor outputs appear in the list of modulation sources, just like the LFOs and Envelopes.
Type
[Gate, Oset, Quantize, Scale, Curve, Smooth, Sum ]
is controls the type of processing performed by the Mod Processor. Each is described in detail below.
Gate
is lets you switch between two modulation sources (or xed values) using a third modulation source.
It’s similar to an audio gate with a side-chain, but with even more exibility–since you get to choose what happens when
the gate is closed (below the threshold), as well as when it’s open (above the threshold).
For instance, you can use Gate to:
• Apply pitch-bend or other eects to some notes, but not to others (using Control at Note-On Only)
• Apply modulation only aer the source reaches a certain threshold–for instance, use Velocity to modulate an LFO’s
frequency, but only once Velocity is greater than 90
• Use a controller to switch between two dierent LFOs (or any two modulation sources)
Control
Below
Above
Fixed Val
Source
Fixed Val
Source
Control
Source
[List of Modulation Sources]
is selects the modulation source to control the Gate.
Threshold
[-100…+100]
is sets the value of the Control Source at which the gate opens or closes.
Control at Note-On Only
[O, On]
When this is On, the value of the Control Source is only evaluated at note-on. e selected output will then remain
active throughout the duration of the note, regardless of any subsequent change in the Control Source’s value. Note that
the output value itself can continue to change; only the selection of Below or At & Above is xed.
