CAV0010068 - AC LINE HARNESS
2 WHITE (N)
NC
1 BLACK (L)
N.2 JST VHR-3N (CON0010027)
L=140mm
1
N.4 JST SVH-41T-P1.1 (CON0010033)
1
2 WHITE (N)
NC
1 BLACK (L)
N.2 NYLON CABLE TIES: RICHCO WIT-E-018R (PLA0001062)
20mm
20mm
CAV0010070 - HARNESS SPS/CONTROL BOARD
3 BLACK
N.1 JST VHR-5N (CON0010029)
L=280mm
1
N.8 JST SVH-41T-P1.1 (CON0010033)
1
N.1 JST VHR-8N (CON0010032)
NC
2 RED
1 RED
4 BLACK
3 BLACK
2 RED
1 RED
NC
NC
NC
NC
4 BLACK
CAV0010071 - HARNESS CONTROL BOARD/MB
4 BLACK
N.2 JST VHR-4N (CON0010028)
L=80mm
1
N.8 JST SVH-41T-P1.1 (CON0010033)
1
3 BLACK
2 ORANGE
1 RED
4 BLACK
3 BLACK
2 ORANGE
1 RED
THERMAL SHRINKING TUBE ALSO ON SHIELD (DRAIN WIRE)
1
1 RED (V)
2 WHITE D-
3 GREEN D+
4 SHIELD (DRAIN)
5 BLACK (GND)
L=610mm
1
5 BLACK (GND)
4 SHIELD (DRAIN)
3 GREEN D+
2 WHITE D-
1 RED (V)
THERMAL SHRINKING TUBE L=15mm
N:2 JST EHR5 (CON0001124)
CAV0010074 - HARNESS MB/FRONT USB
INSERT D- AND D+ IN HOUSING AND
TURN 2 TIME THE HOUSING BEFORE
INSERT ALL OTHER CONNECTIONS
1
1
1
2
2
2
n.2 Complete Turns
RICHCO RT250-150-120-K5B (BOB0001001)
65mm
N.2 THERMAL SHRINKING TUBE L=15mmx2
N.1 USB 2.0 HS (480Mbit/sec) CABLE L=550mm
N.2 JST EHR5 HOUSING (CON0001124)
PARTS LIST
N.10 JST SEH-001T-P0.6 TERMINALS (CON0001127)
N.1 RICHCO RT250-150-120-K5B (BOB0001001)
CAV0010077 - HARNESS SPK AUDIO
N.4 JST SEH-001T-P0.6 (CON0001127)
JST EHR-3 (CON0010024)
1
1
L=300
SHIRINK TUBE L=15MM D=4.8MM
SHIELDED CABLE SUMITOMO AWG24-x1-FRPEFXSV
SHIRINK TUBE ON SHIELD D=1.6 L=32.5MM
PEELING 35mm
2 SHIELD
NC
1 RED
JST EHR-3 (CON0010024)
PEELING 35mm
2 SHIELD
NC
1 RED
CAV0010107 - HARNESS MB/HDD PA3X
1 AWG22 ORANGE
1
1
2 RED (V)
3 GREEN (D+)
4 WHITE (D-)
5 SHIELD (DRAIN)
6 BLACK (GND)
7 AWG22 BROWN
7 AWG22 BROWN
6 BLACK (GND)
5 SHIELD (DRAIN)
4 WHITE (D-)
3 GREEN (D+)
2 RED (V)
1 AWG22 ORANGE
JST EHR-7 HOUSING (CON0001126)
JST EHR-7 HOUSING (CON0001126)
THERMAL SHRINKING TUBE L=20mm
L=430mm
THERMAL SHRINKING TUBE ALSO ON SHIELD (DRAIN WIRE)
PARTS LIST
N.14 JST SEH-001T-P0.6 TERMINALS (CON0001127)
N.2 JST EHR-7 HOUSING (CON0001126)
N.1 USB 2.0 HS (480Mbit/sec) CABLE
N.2 THERMAL SHRINKING TUBE L=20mmx2
N:3 PLA0001062 RICHCO WIT-E-018R
INSERT D- AND D+ IN HOUSING AND
TURN 2 TIME THE HOUSING BEFORE
INSERT ALL OTHER CONNECTIONS
Unsheathing 30mm
1
1
2
2
2
1
100mm
100mm
115mm
115mm
Pa3X 61keys HARNESSES
CAV0010072 - HARNESS HEAD PHONE 61
N.8 JST SEH-001T-P0.6 (CON0001127)
N.2 JST EHR-4 (CON0010025)
1
1
4 GREEN
3 RED
2 BLACK
1 ORANGE
L=1030
4 GREEN
3 RED
2 BLACK
1 ORANGE
adhesive NEOPRENE foil 1.5x30x970mm
fix it around alla cables
L=30
L=30
CAV0010105 - HARNESS JOYSTICK 61 PA3X
n.6 JST SEH-001T-P0.6 code CON0001107
6
JST EHR-03
JST EHR-04
220
5
4
3
2
NC
5
4
3
2
6
1
1
EXCON pn:200106HA001
EXCON 200100TC351 code CON0001063
n.2 PLA0001062
70
CON0001105
CON0001106
CON0001104
RICHCO WIT-E-018R
JST pn:PHR-6
JST SPH-002T-P0.5L code CON0001063
n.6
70
