Korg PA3X User Manual

N.2 JST VHR-3N (CON0010027)

CAV0010085 - HARNESS FCC CIRCUITS=50 P=0.5

L=410mm

FCC FLEXIBLE FLAT CABLE:

N. OF CIRCUITS

STEP

TOTAL LENGHT

50

0.5mm

410mm

0.5+/-0.05

0.3

Ct

S2+/-1.00

S4+/-2.00

S1+/-1.00

S3+/-2.00

S1

S2

S3

S4

Ct

0.30+/-0.05

4mm

4mm

8mm

8mm

0.050mm

UL STANDARD

20624 (80°C/60V)

COPPER

Flame Retardant Polyester

Flame Retardant Polyester

CONDUCTOR

INSULATION

SUPPORT

Operating Temperature

Current Rating

-20/+85°C

1A

CAV0010086 - HARNESS FCC CIRCUITS=33 P=0.5

L=70mm

0.5+/-0.05

0.3

Ct

S2+/-1.00

S4+/-2.00

S1+/-1.00

S3+/-2.00

0.30+/-0.05

FCC FLEXIBLE FLAT CABLE:

N. OF CIRCUITS

STEP

TOTAL LENGHT

33

0.5mm

70mm

S1

S2

S3

S4

Ct

4mm

4mm

8mm

8mm

0.050mm

UL STANDARD

20624 (80°C/60V)

COPPER

Flame Retardant Polyester

Flame Retardant Polyester

CONDUCTOR

INSULATION

SUPPORT

Operating Temperature

Current Rating

-20/+85°C

1A

CAV0010087 - HARNESS FCC CIRCUITS=10 P=1.0

L=120mm

1.0+/-0.05

0.3

Ct

S2+/-1.00

S4+/-2.00

S1+/-1.00

S3+/-2.00

0.30+/-0.05

FCC FLEXIBLE FLAT CABLE:

N. OF CIRCUITS

STEP

TOTAL LENGHT

10

1.0mm

120mm

S1

S2

S3

S4

Ct

5mm

5mm

10mm

10mm

0.050mm

UL STANDARD

20624 (80°C/60V)

COPPER

Flame Retardant Polyester

Flame Retardant Polyester

CONDUCTOR

INSULATION

SUPPORT

Operating Temperature

Current Rating

-20/+85°C

1A

Pa3X 76keys HARNESSES AND FFC CABLES

CAV0010076 - HARNESS SPK POWER SUPPLY

L=430mm

N.6 JST SVH-41T-P1.1 (CON0010033)

1

1

2 RED

1 BLACK

3 GREEN

2 RED

1 BLACK

3 GREEN

CAV0010074 - HARNESS FRON USB EARTH

RING TONGUE

d=3.1mm

d=3.1mm

L=100mm (YELLOW-GREEN)

RING TONGUE

!

!

!

FAST-ON UL/CSA APPROVED

n.2 JST SRA-51T-3 (CON0010167)

CAV0010104 - HARNESS EARTH

RING TONGUE

d=3.2mm

d=4.1mm

L=140mm (YELLOW-GREEN)

RING TONGUE

!

!

!

FAST-ON UL/CSA APPROVED

n.1 JST SRA-51T-3 (CON0010167)

n.1 JST SRT-51T-4FE (CON0010156)

CAV0010069 - HARNESS EARTH/STOPPER

d=4.3mm

RING TONGUE

d=4.3mm

L=250mm (YELLOW GREEN)

!

FAST-ON UL/CSA APPROVED

!

!

G.M.G 32009.51.021 (CON0010157)

RING TONGUE

MINIMUM TRACTION FORCE=40kgf

JST SRB-51T-4 (CON0010159)

G.M.G 32009.51.021 (CON0010157)

JST SRB-51T-4 (CON0010159)

