Kostad DC Wallbox
46
Operating Instructions 10/2020 2010045v10
9 Technical data
9.1.1 Electrical data
Entrance
Supply voltage
3 phases, 400 V
AC: PE, L1, L2, L3
Input voltage range 400 V AC +10%, -15%(50 Hz)
Maximum rated input current & power 33A, 22kVA
Power factor 0,99
Efficiency 96% at nominal output power max. 95.5%
DC output (C)
Maximum output power 22 kW
Output voltage range 150 - 1000V DC (CCS 2)
Maximum output current 80 A DC (CCS 2)
General
DC connection Standard
EN 61851-23 / DIN 70121 / IEC 62196 Mode
4 ISO 15118 in preparation
Cable length DC 4.0 metres +/- 10%
Plug type CCS 2
RFID data
RFID system
ISO/IEC 14443A/B
ISO/IEC 18092
Network connection
GSM / GPRS / UMTS (3G modem) / LTE 4G /
Ethernet 10/100Base
