47
Operating Instructions 10/2020 2010045v10
9.1.2 Mechanical data
Dimension (H x W x D) 650 mm x 500 mm x 230 mm
Weight 62 kg
Dimension incl. packaging (H X W x D) 650 mm x 1200 mm x 800 mm
Weight incl. packaging 65 kg
Mechanical impact protection IK10 / Display IK 8
9.1.3 Environmental data
Protection class IP54
Temperature range operation -30°C to + 50°C
Temperature range - Storage -40 °C to +70 °C
Humidity
5% - 95% RH - (without condensation)
Operating noise level 55 dBA at 25°C
Height 2000 m max.
9.1.4 Certifications
General CE certification
Security IEC 61851-1, IEC 61439-2
EMC EN 61000-6-2, EN 61000-6-3
