3 Operation
Safety instructions regarding work with a full multipurpose bucket
Do not transport loads with a raised loader unit!
When transporting loads, always tilt in the attachment a little toward the
machine, carry it as close as possible to the ground and bear in mind the
required ground clearance!
If it is tilted in in transport position, the multipurpose bucket is moved parallel to
its initial position as the loader unit is raised!
If the multipurpose bucket is unintentionally tilted in to the limit in the raised
position Fig. 124/A, material may fall over the rear of the bucket.
☞Do not tilt in a bucket filled with material in this position
☞Slightly readjust the multipurpose bucket if necessary (tilt out Fig. 124/B)
☞In case of a bulky load:
• Secure the load and if necessary, fit the rear of the bucket with a protection
☞Ensure good visibility of the material you want to pick up and of the work
and travel range
In order to avoid danger when travelling or manoeuvring on slopes with a
full bucket, tilt in the multipurpose bucket fully and set the loader unit to
transport position!
☞Whenever possible, travel in reverse when transporting a bucket loaded
with material on a steep slope
Machine travel on public roads with a full bucket is prohibited in Germany!
Get informed on and follow the legal regulations of your country.
Fig. 124 : Transporting loads with a multipurpose bucket
A
Wrong
B
Right
