BA 348-01 * 2.0 * 34801b610.fm 6-13
Technical data 6
Trailer weight/drawbar load: trailer couplings (option)
Agricultural and forestry
tractors Directive 2003/37 EC
Gross trailer
weight rating
1
1. Bucket certified for travel on public roads must be fitted during trailer operation
Gross drawbar
load rating
Trailer without brakes 400 kg
75 kg
Trailer with brakes
(one braked axle)
1750 kg
Trailer with brakes
(all axles braked)
Ball
2
2. For further indications, see the type label – D-value of ball coupling 17.5
Certification according to Directive 94/20/EC: no. e13 00-1176
1750 kg 75 kg
For the control mark, refer to the machine documentation and the type label on the trailer
coupling
Towing gear
(not the trailer coupling)
Only certified for towing the machine
