BA 348-01 * 2.0 * 34801b340.fm 3-93
Operation 3
Moving material with longer reach
Backfilling with maximum safety and without damaging slopes.
This position allows to move material without damaging slopes or structures.
Picking up remaining material completely
Both bucket halves must touch the ground so that all the material is picked up.
☞Pick up remaining material as follows:
• Fold up the front half of the bucket (multipurpose bucket)
• Tilt out the bucket
• Lower the bucket to the ground. Ensure that both bucket halves touch the ground
• Close and tilt in the multipurpose bucket at the same time
• Raise the bucket with the lift hydraulics
Ansicht_005.iso
Fig. 130 : Filling in material with a multipurpose bucket
Ansicht_003.iso
Fig. 131 : Picking up remaining material with the
multipurpose bucket
