Selecting the EDID
To select the EDID:
1. Press the left or right arrows to access the device setting menu.
2. Press the up or down arrows to select the EDID settings menu.
3. Select the EDID from the following options:
4. Press Enter to accept change.
EDID on the input is set.
Defining HDCP Settings
Enable or disable HDCP on the input via the navigation buttons.
To define HDCP settings:
1. Press the left or right arrows to access the HDCP Settings menu.
2. Press the up or down buttons to select HDMI IN or USB-C IN inputs.
3. For each selected input, press the up or down arrows to select HDCP support mode:
▪ Select ON to enable HDCP support.
▪ Select OFF to disable HDCP support.
4. Press Enter to accept HDCP mode.
Defining Encoder Device Channel Number
Set a device channel number from 1 to 999.
To define the encoder channel number:
1. Press the left or right arrows to access the CH DEFINE menu.
2. Press the up or down arrows to set a first digit (0 to 9).
3. Press left and right arrows to add another digit (0 to 9).
4. Press Enter to accept channel number.
Channel number for this device is defined.
