KDS-SW2-EN7 – Defining KDS-SW2-EN7
5
IR 3.5 Mini Jack
Connect to an IR sensor or emitter for bi-directional signal extension
(even when no AV signal is extended). Expected voltage for IR receiver
- (3.3V).
USB Type A Charging
Ports (1 and 2)
Connect to USB devices, for example, to a speakerphone and
webcam.
HOST USB Type B Port
Connect to a USB host.
HDMI OUT Connector
Connect to loop the signal.
