6. In the Properties (Frame) area, perform any of the following actions:
▪ Click to copy the selected frame properties (Fill, Border Color, Border Width and
Border Radius).
▪ Click to paste frame properties to a selected frame.
▪ Change the frame Name.
▪ Set the position of the frame by moving it (or by entering the x, y coordinates).
▪ Enter frame size (or click Size up/down arrows to change h and w frame size).
▪ Click the Fill color button to change the frame color.
▪ Click the Border Color button to change the border color.
▪ Enter Border Width to change the border width (or use up/down arrows).
▪ Enter Border Radius to change the border edge radius (or use up/down arrows).
▪ Click Show/Hide to show or hide the frame.
7. Click Save Changes.
The frame is configured.
Adding a New Button
The buttons in the Maestro Control panel are designed to carry out an assigned script to run
when that button is pressed.
To add a new button:
1. In the Navigation pane, click Automation. The Automation page appears (see
Figure 39).
2. Click the Panel tab. The default VS-411XS Maestro Control panel appears (see
Figure 43).
3. Click Edit. The Edit panel appears (see Figure 44).
