Kramer VS-88H2

Kramer Electronics Ltd.
VS-88H2 – Protocol 3000 Commands
72
Function
Description
Syntax
Parameters/Attributes
Example
MTX-MODE
LEGACY COMMAND.
Set auto-switch mode.
Not recommended
for new devices.
COMMAND
#MTX-MODEout_id,connection_mode<CR>
FEEDBACK
~nn@MTX-MODEout_id,connection_mode<CR><LF>
out_id – number of system
outputs
* – All outputs
1 – HDMI OUT 1
2 – HDMI OUT 2
3 – HDMI OUT 3
4 – HDMI OUT 4
5 – HDMI OUT 5
6 – HDMI OUT 6
7 – HDMI OUT 7
8 – HDMI OUT 8
connection_mode – Connection
mode
0 – manual
1 – auto priority
2 – auto last connected
Set HDMI OUT 1 to last
connected:
#MTX-MODE1,2<CR>
MTX-MODE?
LEGACY COMMAND.
Get auto-switch
mode.
Not recommended
for new devices.
COMMAND
#MTX-MODE?out_id<CR>
FEEDBACK
~nn@MTX-MODEout_id,connection_mode<CR><LF>
out_id –number of system outputs
1 – HDMI OUT 1
2 – HDMI OUT 2
3 – HDMI OUT 3
4 – HDMI OUT 4
5 – HDMI OUT 5
6 – HDMI OUT 6
7 – HDMI OUT 7
8 – HDMI OUT 8
connection_mode – Connection
mode
0 – manual
1 – auto priority
2 – auto last connected
Get auto-switch mode for
HDMI OUT 2:
#MTX-MODE?2<CR>
NAME
Set machine (DNS)
name.
The machine
name is not the same
as the model name.
The machine name is
used to identify a
specific machine or a
network in use (with
DNS feature on).
COMMAND
#NAMEmachine_name<CR>
FEEDBACK
~nn@NAMEmachine_name<CR><LF>
machine_name – String of up to 14
alpha-numeric chars (can include
hyphen, not at the beginning or end)
Set the DNS name of the
device to room-442:
#NAMEroom-442<CR>
NAME?
Get machine (DNS)
name.
The machine
name is not the same
as the model name.
The machine name is
used to identify a
specific machine or a
network in use (with
DNS feature on).
COMMAND
#NAME?<CR>
FEEDBACK
~nn@NAMEmachine_name<CR><LF>
machine_name – String of up to 14
alpha-numeric chars (can include
hyphen, not at the beginning or end)
Get the DNS name of the
device:
#NAME?<CR>
NAME-RST
Reset machine (DNS)
name to factory
default.
Factory default of
machine (DNS) name
is “KRAMER_” + 4
last digits of device
serial number.
COMMAND
#NAME-RST<CR>
FEEDBACK
~nn@NAME-RSTok<CR><LF>
Reset the machine name
(S/N last digits are 0102):
#NAME-RST<CR>
NET-DHCP
Set DHCP mode.
Only 1 is relevant
for the mode value.
To disable DHCP, the
user must configure a
static IP address for
the device.
Connecting Ethernet
to devices with DHCP
may take more time in
some networks.
To connect with a
randomly assigned IP
by DHCP, specify the
device DNS name (if
available) using the
NAME command. You
can also get an
assigned IP by direct
connection to USB or
RS-232 protocol port,
if available.
For proper settings
consult your network
administrator.
For Backward
compatibility, the id
parameter can be
omitted. In this case,
the Network ID, by
default, is 0, which is
the Ethernet control
port.
COMMAND
#NET-DHCPdhcp_state<CR>
FEEDBACK
~nn@NET-DHCPdhcp_state<CR><LF>
dhcp_state –
1 – Try to use DHCP. (If
unavailable, use the IP
address set by the factory or
the net-ip command).
Enable DHCP mode for
port 1, if available:
#NET-DHCP1<CR>
