VS-88H2 – Protocol 3000 Commands
65
Protocol 3000 Commands
Function
Description
Syntax
Parameters/Attributes
Example
#
Protocol handshaking.
Validates the
Protocol 3000
connection and gets
the machine number.
Step-in master
products use this
command to identify
the availability of a
device.
COMMAND
#<CR>
FEEDBACK
~nn@ok<CR><LF>
#<CR>
AFV
Set audio follow
video/audio
breakaway mode.
When the unit
moves from
breakaway to audio
follow video switching
mode, all audio switch
settings reset
according to the video
switch settings.
COMMAND
#AFVafv_mode<CR>
FEEDBACK
~nn@AFVafv_mode<CR><LF>
afv_mode – Front panel AFV mode
0 – afv – sets the unit to the
audio-follow-video switching
mode
1 – brk – sets the unit to the audio
breakaway switching mode
Set audio breakaway mode:
#AFV1<CR>
AFV?
Get audio follow video
mode status.
When the unit
moves from
breakaway to audio
follow video switching
mode, all audio switch
settings reset
according to the video
switch settings.
COMMAND
#AFV?<CR>
FEEDBACK
~nn@AFVafv_mode<CR><LF>
afv_mode – Front panel AFV mode
0 – afv – sets the unit to the
audio-follow-video switching
mode
1 – brk – sets the unit to the audio
breakaway switching mode
Get audio follow video
mode status:
#AFV?<CR>
AUD
LEGACY COMMAND.
Set audio switch
state.
When AFV
switching mode is
active, this command
cannot switch video.
COMMAND
#AUDin>out_id,in>out_id,…<CR>
FEEDBACK
~nn@AUDin>out_id<CR><LF>
~nn@AUDin>out_id<CR><LF>
in – Input number
0 – disconnect output
1 – HDMI IN 1
2 – HDMI IN 2
3 – HDMI IN 3
4 – HDMI IN 4
5 – HDMI IN 5
6 – HDMI IN 6
7 – HDMI IN 7
8 – HDMI IN 8
> – Connection character between
in and out parameters
out_id – Output number
* – All outputs
1 – HDMI OUT 1
2 – HDMI OUT 2
3 – HDMI OUT 3
4 – HDMI OUT 4
5 – HDMI OUT 5
6 – HDMI OUT 6
7 – HDMI OUT 7
8 – HDMI OUT 8
Switch embedded audio
HDMI IN 1 to HDMI OUT 3:
#AUD1>3<CR>
AUD?
LEGACY COMMAND.
Get audio switch
state.
When AFV
switching mode is
active, this command
cannot switch video.
COMMAND
#AUD?out_id<CR>
#AUD?*<CR>
FEEDBACK
~nn@AUDin>out_id<CR><LF>
~nn@AUDin>1,in>2,…<CR><LF>
in – Input number
1 – HDMI IN 1
2 – HDMI IN 2
3 – HDMI IN 3
4 – HDMI IN 4
5 – HDMI IN 5
6 – HDMI IN 6
7 – HDMI IN 7
8 – HDMI IN 8
> – Connection character between
in and out parameters
out_id – Output number
* – All outputs
1 – HDMI OUT 1
2 – HDMI OUT 2
3 – HDMI OUT 3
4 – HDMI OUT 4
5 – HDMI OUT 5
6 – HDMI OUT 6
7 – HDMI OUT 7
8 – HDMI OUT 8
Get audio switch state for
HDMI OUT 3:
#AUD?3<CR>
