Kramer VS-88H2

Kramer Electronics Ltd.
VS-88H2 – Protocol 3000 Commands
75
Function
Description
Syntax
Parameters/Attributes
Example
PRST-STO
Store current
connections, volumes
and modes in preset.
In most units,
video and audio
presets with the same
number are stored
and recalled together
by commands
#PRST-STO and
#PRST-RCL.
COMMAND
#PRST-STOpreset<CR>
FEEDBACK
~nn@PRST-STOpreset<CR><LF>
preset – Preset number
Store preset 1:
#PRST-STO1<CR>
PRST-VID?
Get video connections
from saved preset.
In most units,
video and audio
presets with the same
number are stored
and recalled together
by commands
#PRST-STO and
#PRST-RCL.
COMMAND
#PRST-VID?preset,out_id<CR>
#PRST-VID?preset,*<CR>
FEEDBACK
~nn@PRST-VIDpreset,in_id>out_id<CR><LF>
~nn@PRST-VIDpreset,>1,>2,>3,…<CR><LF>
preset – Preset number –
1 – Preset 1
2 – Preset 2
3 – Preset 3
4 – Preset 4
5 – Preset 5
6 – Preset 6
7 – Preset 7
8 – Preset 8
9 – Preset 9
10 – Preset 10
11 – Preset 11
12 – Preset 12
13 – Preset 13
14 – Preset 14
15 – Preset 15
16 – Preset 16
In_id
0 – disconnect output
1 – HDMI IN 1
2 – HDMI IN 2
3 – HDMI IN 3
4 – HDMI IN 4
5 – HDMI IN 5
6 – HDMI IN 6
7 – HDMI IN 7
8 – HDMI IN 8
> – Connection character between
in and out parameters
out_id –Output number
* – All outputs
1 – HDMI OUT 1
2 – HDMI OUT 2
3 – HDMI OUT 3
4 – HDMI OUT 4
5 – HDMI OUT 5
6 – HDMI OUT 6
7 – HDMI OUT 7
8 – HDMI OUT 8
Get video connections from
preset 3 for all outputs:
#PRST-VID?3,*<CR>
REMOTE-
INFO?
Get connected Step-in
module information.
The matrix uses
this command to
notify about Step-in
client changes.
COMMAND
#REMOTE-INFO?io_mode,io_index<CR>
FEEDBACK
~nn@REMOTE-INFOio_mode,io_index,connected_state,
model_name,in_selected,step-in_state,in_count,
cntl_btn_count,in_src1,in_src2…<CR><LF>
io_mode – Input/Output
0 – Input
1 – Output
io_index – Number that indicates
the specific input or output port:
1 – HDMI IN 1
2 – HDMI IN 2
3 – HDMI IN 3
4 – HDMI IN 4
5 – HDMI IN 5
6 – HDMI IN 6
7 – HDMI IN 7
8 – HDMI IN 8
1 – HDMI OUT 1
2 – HDMI OUT 2
3 – HDMI OUT 3
4 – HDMI OUT 4
5 – HDMI OUT 5
6 – HDMI OUT 6
7 – HDMI OUT 7
8 – HDMI OUT 8
connected_state – 0/1 (if
module connected)
model_name – Model name string
in_selected – Input, currently
chosen on module
step-in_state – Step-in state
0 – module doesn’t support Step-
in
1 – module supports Step-in
None
in_count – 8
cntl_btn_count – Number of
control buttons on module
in_src – Type2… typeN – Input
type according to num_of_inputs
0 – Undefined
2 – HDMI
Get connected Step-in
module information for
HDMI IN 1:
#REMOTE-INFO?0,1<CR
>
