3 Machine Description
3.2 Labelling
32
ActiveMow R 200
Original Operating Instructions 150000521_04_en
3.2 Labelling
INFORMATION
The entire identification plate represents a legal document and should not be altered or
rendered illegible!
KMG000-021
The machine data are specified on the type plate (1). The type plate is mounted on the face
side on the three-point hitch.
Information for enquiries and orders
If you have any further queries on the machine or if you want to order spare parts, always enter
type designation, vehicle identification number and year of manufacture of the corresponding
machine. To ensure that these data are always available, we recommend to enter them in the
fields on the front cover page of these operating instructions.
3.3 Pole protection mechanism
WARNING
Risk of accident due to changed driving behaviour
If the value for the spring on the impact damage protection system is changed, the trigger
moment of the impact damage protection system also changes. As a result, the impact
damage protection system may trigger in the transport position in case of abrupt loads and
the driving behaviour may change. This can lead to accidents.
Never change the value for the spring on the impact damage protection system.
NOTICE
Machine damage due to impact damage protection system which does not engage
automatically when reversing.
If the impact damage protection system does not engage automatically when reversing, the
machine may be damaged.
Relieve the relief spring(s) and reverse until the impact damage protection system
engages, Adjusting the relief spring(s).
