Information on This Document 1
How to use this document 1.5
ActiveMow R 200
Original Operating Instructions 150000521_04_en 9
WARNING
Eye damage caused by flying dirt particles
When cleaning with compressed air, dirt particles are ejected at high speed and could get into
the eyes. Therefore eyes could be hurt.
Keep people away from the working area.
Wear personal protective equipment when performing cleaning work with compressed air
(e.g. eye protection).
Warnings of property damage/environmental damage
Warnings of property damage/environmental damage are separated from the remaining text
and marked with “Note”.
Example:
NOTICE
Gearbox damage due to low oil level
The gearboxes could be damaged when the oil level is too low.
Check gearbox oil level at regular intervals and top up oil, if necessary.
Check gearbox oil level approx. 3 to 4 hours after the machine has been switched off.
Check oil level only when machine is in horizontal position.
Notes with information and recommendations
Additional information and recommendations for trouble-free and productive operation of the
machine are separated from the remaining text and marked with “Information”.
Example:
INFORMATION
Each safety label is provided with an order number and can be ordered directly from the
manufacturer or from the authorized specialist dealer.
1.5.7 Conversion table
The following table can be used to convert metric units into US units.
Size SI units (metric) Factor Inch-pound units
Unit name Abbrevi-
ation
Unit name Abbrevi-
ation
Area Hectare ha 2.47105 Acre acres
Volume flow Litres per minute L/min 0.2642 US gallons per
minute
gpm
Cubic metres
per hour
m³/h 4.4029
Force Newton N 0.2248 Pound force lbf
Length Millimetre mm 0.03937 Inch in.
Metre m 3.2808 Foot ft.
Power Kilowatt kW 1.3410 Horsepower hp
