7 Start-up
7.3 Installing universal shaft
42
ActiveMow R 200
Original Operating Instructions 150000521_04_en
7.3 Installing universal shaft
WARNING
Risk of injury by failure to take account of the danger zone of the universal shaft
If the danger zone of the universal shaft is ignored, persons can be seriously hurt or killed.
 To avoid accidents, observe the danger zone of the universal shaft, refer to page16.
NOTICE
Changing the tractor
The machine could be damaged if the universal shaft length is not checked when changing
the tractor.
 In order to avoid damage to the machine, check universal shaft length every time the
tractor is changed and correct it, if necessary, refer to page39.
KMG000-048
ü The machine is shut down and safeguarded, refer to page24.
 Slide universal shaft (1) on PTO shaft end of tractor and secure it.
 Secure universal shaft guard by means of supporting chain (2) against turning.
