Settings 10
Setting the mower in working position 10.1
ActiveMow R 200
Original Operating Instructions 150000521_04_en 53
10 Settings
WARNING
Risk of injury due to non-observance of relevant safety instructions
If the relevant safety instructions are not observed, persons may be seriously injured or killed.
To avoid accidents, the relevant safety instructions must be read and observed, refer to
page12.
WARNING
Risk of injury due to non-observance of safety instructions
If the relevant safety routines are not observed, persons may be seriously injured or killed.
The safety routines must be read and observed to avoid accidents, refer to page24.
10.1 Setting the mower in working position
KM000-431
If the bolt (1) is centred above the marking arrow (2), the optimal working height of the machine
is set.
ü The machine is in the working position, refer to page47.
ü The machine is shut down and safeguarded, refer to page24.
To set the working height, raise or lower the lower link
10.2 Setting the cutting height
KMG000-035
The cutting height is adjusted via the top link(1).
