Krone ActiveMow R 200 User Manual

14 Maintenance - Cutterbar
14.3 Check/change blades
70
ActiveMow R 200
Original Operating Instructions 150000521_04_en
KM000-038
ü The machine is in the working position, refer to page47.
ü The machine is shut down and safeguarded, refer to page24.
ü The front guard is folded up, refer to page43.
 Clean the area around the blades, cutting discs and mower drums.
 Check wear limit.
ð If the dimension is X>13mm, the wear limit is not reached.
ð If the dimension is X≤13mm or the borehole touches the marking (1), the blade must
be replaced.
14.3.2 Changing blades for the “blade screw connection” version
KM000-044
ü The machine is in the working position, refer to page47.
ü The machine is shut down and safeguarded, refer to page24.
ü The front guard is folded up, refer to page43.
ü The area around blades, cutting discs and mower drums is cleaned.
 Dismount damaged or worn blade.
 Check mounting parts of blade, refer to page72. Also replace worn or damaged mounting
parts.
