8 Operation
8.2 Operating support jack
44
ActiveMow R 200
Original Operating Instructions 150000521_04_en
KM000-434
ü The machine is in the working position, refer to page47.
ü The machine is shut down and safeguarded, refer to page24.
 Pull the spring cotter pin (3) and pull the locking (2) off the bolt.
 Fold up the front guard(1), place the locking(2) onto the bolt and secure it with the spring
cotter pin(3).
8.1.2 Folding down front guard
KM000-439
ü The machine is in the working position, refer to page47.
ü The machine is shut down and safeguarded, refer to page24.
 Pull the spring cotter pin (3) and pull the locking (2) off the bolt.
 Fold down the front guard(1), place the locking(2) onto the bolt and secure it with the
spring cotter pin(3).
8.2 Operating support jack
INFORMATION
In order to increase the base of the support jack when the ground is soft, use a suitable
support.
