Krone ActiveMow R 200 - Setting the Relief Spring for the Carrying Bar

Settings 10
Increasing/reducing ground pressure 10.3
ActiveMow R 200
Original Operating Instructions 150000521_04_en 55
10.3.1 Setting the relief spring for the carrying bar
KM000-429
The inside of the cutterbar is loaded or relieved via the relief spring (1) of the carrying bar.
ü The machine is in the headland position.
ü The machine is shut down and safeguarded, refer to page24.
 To reduce the ground pressure, turn the spindle (2) in direction +.
 To increase the ground pressure, turn the spindle (2) to the direction -.
