Maintenance - General Information 11
Tightening torques 11.2
ActiveMow R 200
Original Operating Instructions 150000521_04_en 59
Metric thread screws with fine thread
DV000-001
X Thread size 1 Strength class on screw head
X Strength class
5.6 8.8 10.9 12.9
Tightening torque (Nm)
M12 x 1.5 88 130 152
M14 x 1.5 145 213 249
M16 x 1.5 222 327 382
M18 x 1.5 368 525 614
M20 x 1.5 465 662 775
M24 x 2 787 1,121 1,312
M27 x 2 1,148 1,635 1,914
M30 x 1.5 800 2,100 2,650
Metric thread screws with countersunk head and hexagon socket
INFORMATION
The table applies only to countersunk screws with hexagon socket and metric thread
tightened via hexagon socket.
DV000-000
X Thread size 1 Strength class on screw head
