12 SERVICE WORK ON THE CHASSIS 101
12.21 Installing the right side cover
S00782-10
– Position the side cover.
–
Mount and tighten screws
.
Guideline
Screw, side cover M6 6 Nm (4.4 lbf ft)
–
Push on the side cover in area
.
The holding lug engages in the drilled hole on the front spoiler.
–
Mount and tighten screws
.
Guideline
Screw, side cover on front fairing M6 7 Nm (5.2 lbf ft)
M00455-10
–
Mount expanding rivet
.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KTM 2016 RC 390 and is the answer not in the manual?

KTM 2016 RC 390 Specifications

General IconGeneral
Displacement373.2 cc
Bore x Stroke89 mm x 60 mm
Compression Ratio12.6:1
Power32 kW (44 hp) @ 9, 500 rpm
Torque35 Nm @ 7, 250 rpm
Transmission6-speed
Rear SuspensionWP monoshock
Rear Brake230 mm disc, single-piston caliper
Front Tire110/70 ZR17
Rear Tire150/60 ZR17
Seat Height820 mm
Fuel Tank Capacity10 liters
Dry Weight147 kg
Ground Clearance178.5 mm
Engine TypeSingle-cylinder, 4-stroke
Fuel SystemElectronic Fuel Injection
Front SuspensionWP USD 43 mm
ABSBosch 9MB Two-Channel ABS
FrameSteel trellis frame
Front Brake300 mm disc, 4-piston radial caliper
