KTM 2016 RC 390 User Manual

6 CONTROLS 24
6.5 Light switch
L02113-11
The light switch

is fitted on the left side of the handlebar.
Possible states
Low beam on – Light switch is turned downward. In this position, the low
beam and tail light are switched on.
High beam on – The light switch is turned upwards. In this position, the
low beam, the high beam and the tail light are switched on.
6.6 High beam flasher button
L02113-12
The high beam flasher button

is fitted on the left side of the handlebar.
Possible states
• High beam flasher button in neutral position
• High beam flasher button pressed – In this position, the headlight flasher (high beam)
is actuated.

KTM 2016 RC 390 Specifications

General

Displacement	373.2 cc
Bore x Stroke	89 mm x 60 mm
Compression Ratio	12.6:1
Power	32 kW (44 hp) @ 9, 500 rpm
Torque	35 Nm @ 7, 250 rpm
Transmission	6-speed
Rear Suspension	WP monoshock
Rear Brake	230 mm disc, single-piston caliper
Front Tire	110/70 ZR17
Rear Tire	150/60 ZR17
Seat Height	820 mm
Fuel Tank Capacity	10 liters
Dry Weight	147 kg
Ground Clearance	178.5 mm
Engine Type	Single-cylinder, 4-stroke
Fuel System	Electronic Fuel Injection
Front Suspension	WP USD 43 mm
ABS	Bosch 9MB Two-Channel ABS
Frame	Steel trellis frame
Front Brake	300 mm disc, 4-piston radial caliper
