15 ELECTRICAL SYSTEM 123
15.1 Removing the battery
Warning
Risk of injuryBattery acid and battery gases cause serious chemical burns.
Keep batteries out of the reach of children.
Wear suitable protective clothing and goggles.
Avoid contact with battery acid and battery gases.
Keep sparks and open flames away from the battery. Only charge in well-ventilated rooms.
In the event of skin contact, rinse with large amounts of water. If battery acid gets in the eyes, rinse with water for at least 15
minutes and contact a physician.
Preparatory work
Remove the front rider's seat. ( p. 81)
Remove the battery cover. ( p. 91)
L02156-10
Main work
Pull back the negative terminal cover
.
Disconnect negative cable
from the battery.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KTM 2016 RC 390 and is the answer not in the manual?

KTM 2016 RC 390 Specifications

General IconGeneral
Displacement373.2 cc
Bore x Stroke89 mm x 60 mm
Compression Ratio12.6:1
Power32 kW (44 hp) @ 9, 500 rpm
Torque35 Nm @ 7, 250 rpm
Transmission6-speed
Rear SuspensionWP monoshock
Rear Brake230 mm disc, single-piston caliper
Front Tire110/70 ZR17
Rear Tire150/60 ZR17
Seat Height820 mm
Fuel Tank Capacity10 liters
Dry Weight147 kg
Ground Clearance178.5 mm
Engine TypeSingle-cylinder, 4-stroke
Fuel SystemElectronic Fuel Injection
Front SuspensionWP USD 43 mm
ABSBosch 9MB Two-Channel ABS
FrameSteel trellis frame
Front Brake300 mm disc, 4-piston radial caliper
