KTM 2016 RC 390 User Manual

7 COMBINATION INSTRUMENT 41
7.6 Display
401685-11
The speed

is shown in kilometers per hour km/h or in miles per hour mph.
The tachometer

shows the engine speed in revolutions per minute.
The gear display

shows the engaged gear.
The coolant temperature appears in segment

.
The time appears in segment

.
The filling level in the fuel tank is displaced in segment

.
The info display

shows additional information.
Info
The time must be reset after the battery was disconnected or the fuse was removed.
The intensity of the LED display depends on the ambient brightness.

KTM 2016 RC 390 Specifications

General

Displacement	373.2 cc
Bore x Stroke	89 mm x 60 mm
Compression Ratio	12.6:1
Power	32 kW (44 hp) @ 9, 500 rpm
Torque	35 Nm @ 7, 250 rpm
Transmission	6-speed
Rear Suspension	WP monoshock
Rear Brake	230 mm disc, single-piston caliper
Front Tire	110/70 ZR17
Rear Tire	150/60 ZR17
Seat Height	820 mm
Fuel Tank Capacity	10 liters
Dry Weight	147 kg
Ground Clearance	178.5 mm
Engine Type	Single-cylinder, 4-stroke
Fuel System	Electronic Fuel Injection
Front Suspension	WP USD 43 mm
ABS	Bosch 9MB Two-Channel ABS
Frame	Steel trellis frame
Front Brake	300 mm disc, 4-piston radial caliper
