7 COMBINATION INSTRUMENT 35
7.2 Activation and test
401686-01
Activation
The combination instrument is activated when the ignition is switched on.
Test
The segments of the tachometer and the gear display light up and switch off in sequence.
The speed display counts from 0 to 199 and back.
The remaining display segments outside the info display light up briefly.
The READY TO RACE >> logo appears on the info display.
The display then changes to the last selected mode.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KTM 2016 RC 390 and is the answer not in the manual?

KTM 2016 RC 390 Specifications

General IconGeneral
Displacement373.2 cc
Bore x Stroke89 mm x 60 mm
Compression Ratio12.6:1
Power32 kW (44 hp) @ 9, 500 rpm
Torque35 Nm @ 7, 250 rpm
Transmission6-speed
Rear SuspensionWP monoshock
Rear Brake230 mm disc, single-piston caliper
Front Tire110/70 ZR17
Rear Tire150/60 ZR17
Seat Height820 mm
Fuel Tank Capacity10 liters
Dry Weight147 kg
Ground Clearance178.5 mm
Engine TypeSingle-cylinder, 4-stroke
Fuel SystemElectronic Fuel Injection
Front SuspensionWP USD 43 mm
ABSBosch 9MB Two-Channel ABS
FrameSteel trellis frame
Front Brake300 mm disc, 4-piston radial caliper
