23 TECHNICAL DATA 173
Nut, water pump impeller M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Oil nozzle M6 6 Nm (4.4 lbf ft) Loctite
®
243™
Plug, water pump drain hole M6 8 Nm (5.9 lbf ft) –
Screw, alternator cover M6 12 Nm (8.9 lbf ft) –
Screw, bearing retainer M6 12 Nm (8.9 lbf ft) Loctite
®
243™
Screw, camshaft bearing bridge M6 11 Nm (8.1 lbf ft) –
Screw, camshaft, decompression shaft M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, chain securing guide M6 11 Nm (8.1 lbf ft) Loctite
®
243™
Screw, clutch cover M6 12 Nm (8.9 lbf ft) –
Screw, clutch spring M6 10 Nm (7.4 lbf ft) –
Screw, engine case M6x35 12 Nm (8.9 lbf ft) Loctite
®
243™
Screw, engine case M6x75 12 Nm (8.9 lbf ft) –
Screw, engine sprocket M6 11 Nm (8.1 lbf ft) –
Screw, engine vent plate M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, freewheel gear retaining bracket M6 12 Nm (8.9 lbf ft) Loctite
®
243™
Screw, lock washer, engine sprocket M6 12 Nm (8.9 lbf ft) Loctite
®
243™
Screw, locking lever M6 12 Nm (8.9 lbf ft) Loctite
®
243™
Screw, oil filter cover M6 12 Nm (8.9 lbf ft) –
Screw, oil pump M6 12 Nm (8.9 lbf ft) Loctite
®
243™
Screw, retaining bracket M6 12 Nm (8.9 lbf ft) Loctite
®
243™
Screw, retaining bracket, clutch cable
pull
M6 6 Nm (4.4 lbf ft) Loctite
®
243™
Screw, retaining bracket, shaft seal ring,
clutch cover
M6 11 Nm (8.1 lbf ft) Loctite
®
243™
Screw, shift drum locating M6 12 Nm (8.9 lbf ft) Loctite
®
243™

KTM 2016 RC 390 Specifications

General

Displacement	373.2 cc
Bore x Stroke	89 mm x 60 mm
Compression Ratio	12.6:1
Power	32 kW (44 hp) @ 9, 500 rpm
Torque	35 Nm @ 7, 250 rpm
Transmission	6-speed
Rear Suspension	WP monoshock
Rear Brake	230 mm disc, single-piston caliper
Front Tire	110/70 ZR17
Rear Tire	150/60 ZR17
Seat Height	820 mm
Fuel Tank Capacity	10 liters
Dry Weight	147 kg
Ground Clearance	178.5 mm
Engine Type	Single-cylinder, 4-stroke
Fuel System	Electronic Fuel Injection
Front Suspension	WP USD 43 mm
ABS	Bosch 9MB Two-Channel ABS
Frame	Steel trellis frame
Front Brake	300 mm disc, 4-piston radial caliper
