17 KTM POWERPACK, BATTERY CHARGER
114
C00815-10
Main work
–
Remove
1
charging socket protection cap.
Warning
Risk of injury The intrinsic safety of the
KTM PowerPack can only be guaranteed if the original
battery charger is used.
The KTM PowerPack may only be charged with the
original battery charger.
– Only use the original battery charger to charge the
KTM PowerPack.
– Connect the battery charger to the KTM PowerPack. Observe
plug markings
A
.
C00768-10
– Connect the power plug for the battery charger to the mains
connection.
–
Set the charging mode switch
2
to the Storageposition.
C00769-10
–
Switch on the battery charger using switch
3
.
Charging starts automatically. The status indicator flashes
during the charging process.
C00854-01
– Monitor the charging level of the KTM PowerPack using the
LEDs.
LED 1: 20%
LED 2: 40 %
After the charging process is completed to a level of 50%,
LEDs 1 and 2 light up and the status indicator goes out.
