KTM Freeride E-XC 2019 - Chassis Tightening Torques

TECHNICAL DATA 24
135
Spring rate
Weight of rider: 65 … 75 kg (143 … 165 lb.) 66 N/mm (377 lb/in)
Weight of rider: 75 … 85 kg (165 … 187 lb.) 68 N/mm (388 lb/in)
Weight of rider: 85 … 95 kg (187 … 209 lb.) 69 N/mm (394 lb/in)
Spring length 200 mm (7.87 in)
Gas pressure 10 bar (145 psi)
Static sag 30 mm (1.18 in)
Riding sag 90 mm (3.54 in)
Fitted length 367 mm (14.45 in)
Damper oil Shock absorber fluid (SAE 2.5)
(50180751S1) ( p. 138)
24.9 Chassis tightening torques
Screw for spoiler, top EJOT PT
®
K60x20AL 3 Nm (2.2 lbf ft)
Screw, front spoiler EJOT PT
®
K60x30‑Z 3 Nm (2.2 lbf ft)
Screw, fixed grip M4 5 Nm (3.7 lbf ft)
Loctite
®
243™
Spoke nipple M4.5 6 Nm (4.4 lbf ft)
Screw, shock absorber adjusting
ring
M5 5 Nm (3.7 lbf ft)
Screws, throttle grip M5 3 Nm (2.2 lbf ft)
KTM PowerPack attachment M6 10 Nm (7.4 lbf ft)
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft)
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
Screw for spoiler attachment M6 5 Nm (3.7 lbf ft)
Screw, front brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, radiator bracket M6 6 Nm (4.4 lbf ft)
Screw, rear brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
KTM PowerPack attachment M8 15 Nm (11.1 lbf ft)
Loctite
®
243™
Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft)
Loctite
®
2701™
Nut, rim lock M8 10 Nm (7.4 lbf ft)
Remaining nuts, chassis M8 25 Nm (18.4 lbf ft)
Remaining screws, chassis M8 25 Nm (18.4 lbf ft)
Screw, bottom triple clamp M8 18 Nm (13.3 lbf ft)
Screw, chain sliding piece M8 15 Nm (11.1 lbf ft)
Screw, fork stub M8 15 Nm (11.1 lbf ft)
Screw, front brake caliper M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, handlebar clamp M8 20 Nm (14.8 lbf ft)
Screw, rear brake caliper M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, side stand attachment M8 25 Nm (18.4 lbf ft)
Loctite
®
2701™
