KTM Freeride E-XC 2019 - Installing the Spoiler

13 SERVICE WORK ON THE CHASSIS
70
A00190-10
–
Remove screw
2
.
–
Remove screw
3
.
– Take off the spoiler.
– Repeat the operation on the opposite side.
13.21 Installing the spoiler
A00219-10
Main work
–
Position the spoiler and hook it in at area
A
.
A00190-11
–
Mount and tighten screw
1
.
Guideline
Screw for spoiler, top EJOT PT
®
K60x20AL
3 Nm (2.2 lbf ft)
–
Mount and tighten screw
2
.
Guideline
Screw for spoiler
attachment
M6 5 Nm (3.7 lbf ft)
F01211-11
–
Mount and tighten screws
3
.
Guideline
Screw, front spoiler EJOT PT
®
K60x30‑Z
3 Nm (2.2 lbf ft)
– Repeat these steps on the opposite side.
Finishing work
– Install the KTM PowerPack. ( p. 108)
– Lock the seat. ( p. 69)
