CONTROLS 6
19
6.1 Front brake lever
A00173-10
Front brake lever
1
is fitted on the right side of the handlebar.
6.2 Rear brake lever
A00174-10
Rear brake lever
1
is fitted on the left side of the handlebar.
6.3 Throttle grip
A00175-10
The throttle grip
1
is fitted on the right side of the handlebar.
6.4 Main switch
A00175-11
The main switch
1
is attached to the right side of the handlebar.
The main switch is also used as an emergency OFF switch.
Possible states
Vehicle switched off. – The vehicle is switched off in
this position.
Vehicle ready for operation – The vehicle is ready for
operation in this position. The start button is active.
