6 CONTROLS 11
6.1 Clutch lever
L00464-10
The clutch lever
1
is fitted on the left side of the handlebar.
6.2 Hand brake lever
L00463-10
The hand brake lever
1
is fitted on the right side of the handlebar.
The hand brake lever operates the front brake.
6.3 Throttle grip
L00463-11
The throttle grip
1
is fitted on the right side of the handlebar.
6.4 Ignition switch
L00462-10
The ignition switch
1
is fitted on the right side of the handlebar.
Possible states
Ignition off – In this position, the ignition circuit is interrupted, a run-
ning engine stops, and a non-running engine will not start.
Ignition on – In this position, the ignition circuit is closed, and the
engine can be started.
6.5 Tail light switch
L00465-11
The tail light switch
1
is fitted on the left side of the handlebar.
Possible states
Tail light off – The tail light switch is not pushed in. In this position,
the tail light is switched off.
Tail light on – The tail light switch is pushed in. In this position, the
tail light is switched on.
