6 CONTROLS 14
6.11 Combination instrument 1/2
3-1
Select button
The RPM shift light
Setting range:5,000~16,000 RPM.
Setting unit:100 RPM.
Pre-shift light
Setting range:
-500~-5,000 RPM.
Setting unit: 100 RPM.
The Digital
Display range:0~16,000 RPM.
Display range:100 RPM.
tachometer
Adjust button
Tachometer (16,000 RPM)
Display range: 0~16,000 RPM.
O
o
Setting range: 6 (140~302 F)
o
Setting unit: (1 F)
ver heat warning light
o
0~150 C .
o
1C .
T
oo
Display range: 0~150 C (32~302 F).
oo
Display unit: 1 C (1 F).
hermometer
Overview
Shift light
(Red light)
Pre-shift light
(Yellow light)
o
-10~+60 C
Eective temperature range
Stroke / piston setting
2 Stroke: 1, 2, 3, 4 pistons
4 Stroke: 1, 2, 3, 4, 5, 6, 8, 10, 12 pistons
Setting range: 5,000~16,000 RPM
Setting unit: 100 RPM
Shift light
3-2
oo
Display range: 0~150 C 0~302 F
oo
Display unit: 0.1 C 0.1 F
Display unit: 100 RPM
Setting range: -500~-5,000 RPM
Setting unit: 100 RPM
Over heat warning light
oo
Setting range: 60~150 C 140~302 F
oo
Setting unit: 1 C 1 F
135.7 X 100.7 X 52 mm
Needle tachometer
Digital tachometer
Display range: 0~16,000 RPM
Display range: 0~16,000 RPM
<0.5 second
Display internal
<0.5 second
Display internal
Meter standard
JIS D 0203 S2
Meter size
Meter weight
Around 240 g
Function, setting instruction
Battery type
9V-1604, 6LR61
Thermometer
Pre-Shift light
Design and specication are subject to change without notice!
4-1
Press Adjust button one time to switch the
oo
temperature unit between C and F.
In the main screen, press down the Select &
Adjust button together for 3 seconds to enter
the setting screen.
4-2
Cycle / Piston / Input signal setting
Adjust button
EX. To change the setting to 4 stroke.
Press the to select the stroke.
EX. Now the setting is 2C (2 Stroke).
You could set the stroke as 2 stroke or 4
stroke.
CAUTION!
Make sure the correct str okes and pistons before setting.
Make sure the input is correct, or the RPM output will be
incorrect.
We dene the engine with the ignition system ignites every
360 degree as 2-stroke and the engine with the ignition
system ignites every 720 degree as 4-strok e.
Some 4-stroke bikes with one single piston are igniting every
360 degree once, so the setting should be the same as the
bike with 2-stroke and one piston engine.
Press the Select button to enter the piston
setting screen.
EX. Now the setting is changed from 2 cycle
to 4 cycle.
2 Cycle: 1,2,3,4 pistons
4 Cycle: 1,2,3,4,5,6,8,10,12 pistons
EX. To change the setting to 4piston.
Press the Adjust button to select the piston
digit.
EX. Now the setting is 1P (1 piston).
Adjust button function instruction
The digit you could set is ashing now .
The digit you could set is ashing now .
L00580-01
