11 SERVICE WORK ON THE CHASSIS 41
L00516-11
–
Mount and tighten screws
4
.
Guideline
Remaining chassis screws M6 12 Nm (8.9 lbf ft)
11.14 Checking the fuel overflow reservoir
L00594-11
–
Check the fluid level in the fuel overflow reservoir
1
.
» If there is fluid in the fuel overflow reservoir:
– Empty the fuel overflow reservoir. ( p. 41)
11.15 Emptying the fuel overflow reservoir
Warning
Danger of poisoning Fuel is poisonous and a health hazard.
– Fuel must not come into contact with the skin, eyes, or clothing. Do not breathe in the fuel vapors. If contact occurs with
the eyes, rinse with water immediately and contact a physician. Immediately clean contaminated areas on the skin with
soap and water. If fuel is swallowed, contact a physician immediately. Change clothing that is contaminated with fuel.
Warning
Environmental hazard Improper handling of fuel is a danger to the environment.
– Do not allow fuel to get into the ground water, the ground, or the sewage system.
Preparatory work
– Remove the engine cowl. ( p. 38)
– Remove the front fairing. ( p. 38)
L00594-12
Main work
–
Remove cable ties
1
.
–
Open cover
2
and empty the fuel overflow reservoir.
– Close the cover.
– Position the fuel overflow reservoir.
– Mount the new cable ties.
Finishing work
– Install the front fairing. ( p. 39)
– Install the engine cowl. ( p. 38)
